₹15,000.00
The DRV 80A ESC delivers robust propulsion performance with reliable protection features designed for demanding UAV applications. Its intelligent drive algorithm enables stable motor operation, smoother throttle management, and rapid RPM response across a wide power range. With support for RPM/PWM input and CAN communication, the ESC integrates seamlessly with modern flight controllers, enabling synchronized propulsion, telemetry feedback, and enhanced safety management.
The ESC includes a full set of protection mechanisms against overload, temperature rise, voltage irregularities, and throttle loss—making it well-suited for professional drones, VTOL aircraft, power-hungry multirotors, and long-duration industrial missions.
The DRV 80A (5–14S) is a high-performance electronic speed controller designed for UAVs that require fast response, high current capability, and precise control. With support for PWM and CAN communication, it delivers smooth propulsion for VTOL systems, multirotors, and industrial-grade aerial platforms.
| Input Voltage | 5S – 14S LiPo |
|---|---|
| Continuous Current | 80A |
| Maximum Current | 120A (with cooling) |
| Control Modes | PWM + CAN |
| PWM Signal Voltage | 3.3V / 5V compatible |
| Signal Frequency | 50 – 500 Hz |
| Throttle Pulse Width | 1050 – 1940 µs |
| Voltage Protection | Supported |
| Temperature Protection | Supported |
| Stall Protection | Supported |
| Short Circuit Protection | Supported |
| Throttle Loss Protection | Supported |
| Startup Protection | Supported |
| Firmware Update | Online update supported |
| BEC | 5V / 200 mA |
| Dimensions | 79.6 × 36 × 23.5 mm |
| Operating Temperature | –20°C to 65°C |
| Weight | ~140 g |
| Power Wires | 12 AWG (800 mm) |
| Motor Wires | 14 AWG (150 mm) |
| Signal Cable Length | 1000 mm |
| IP Rating | IP67 |
| Beep Pattern | Issue | Cause | Solution |
| Beep… (every 1s) | Motor will not start | Throttle signal lost | Adjust throttle bottom; check receiver connection |
| Fast beep-beep-beep | Motor will not start | Throttle not at zero | Move throttle stick to the lowest position |
| Beep-beep (every 1s) | Low voltage | Battery < 16V | Use a fully charged battery |
| Beep-beep (every 1s) | High voltage | Battery > 64V | Switch to correct battery |
| Beep-beep-beep (every 1s) | ESC overheating | Temperature > 125°C | Allow ESC to cool in ventilation |
| Beep-beep-beep-beep (every 1s) | Startup or overload issue | Incorrect propeller or overload | Use proper propeller size |
The DRV 80A ESC is built for UAV platforms requiring high thrust, fast response, and long-term reliability. Its synchronous freewheeling architecture ensures smoother throttle transitions, reduced switching loss, and improved efficiency across all RPM ranges. With a rugged IP67 waterproof and corrosion-resistant enclosure, the ESC maintains stable performance in harsh outdoor environments, including rain, dust, and wet-landing operations.
It supports 5S to 14S LiPo batteries.
Yes, the ESC supports CAN as well as PWM input.
Common causes include the throttle not at zero, low/high voltage, or signal loss.
At 125°C, power is reduced. At 140°C, the ESC shuts down until it cools below 80°C.
Yes, it includes a 5V / 200 mA BEC output.
Possible causes include overload, incorrect propeller size, or the engagement of stall protection.
Yes, the ESC is IP67-rated, offering strong protection against dust, water, and corrosion.
